AMD/Xilinx Zynq™ UltraScale+™-based high-speed digital signal conversion scalable module
.png)
| Item | XSOM M012B | XSOM M013B | XSOM M014B |
|---|---|---|---|
| Xilinx Zynq UltraScale + RFSoC | XCZU43/47DR, XQZU48DR | XCZU43/47DR, XQZU48DR | XCZU43/47DR, XQZU48DR |
| RX | 8-RX Single Ended (SMPM) | 4-RX Single Ended (SMPM) | - |
| TX | - | 4-TX Single Ended (SMPM) | 8-TX Single Ended (SMPM) |
| ADC | 8-14Bit RF ADC | 4-14Bit RF ADC | - |
| DAC | - | 4-14Bit RF DAC | 8-14Bit RF DAC |
| Size (mm) | 65 x 103 | 65 x 103 | 65 x 103 |
